Uploaded January 2023 | Updated September 2026, 2 hours ago

---

In this video, I walk through the complete touch probe calibration procedure on the SYIL X7 and X9 with the Syntec 22MA control.

I show how to indicate the probe, verify the setup, run the calibration routine, and confirm the resulting probe height value in the tool table.

This is the procedure to use when setting up a new probe, replacing a probe, changing the stylus, or anytime the touch probe calibration needs to be verified.

Covered in this video:

Indicating the touch probe
Checking probe alignment
Running the probe calibration macro
Calibrating probe height
Verifying the stored probe value
Syntec 22MA probe setup
SYIL X7 and X9 touch probe calibration


Touch Probe Stylus 3mm amzn.to/3WHuMyS
Noga DG61003 Mag Base amzn.to/3X5OFj3
Mitutoyo 513-473-10E amzn.to/3Il8heW
INSIZE 6313-1 Setting Ring, 1.0" Diameter amzn.to/3CjxhiA
INSIZE 6296-2 Dial Test Indicator Holder amzn.to/3X2okCs
Tegara BT30 ER20 Tool Holder amzn.to/3GxxuBj
Techniks 1/4" Super Precision ER20 Collet amzn.to/3Qd9LJK
Tegara BT30 M12 45 Pull Stud amzn.to/3Z9Y0rV
Tschorn 00163B05I Dial 3D Taster amzn.to/3X5RsJ3
