Uploaded April 2025 | Updated September 2026, 3 weeks ago

---

Parts linked in the description below!

Watch a full tutorial as this 2009 Dodge Sprinter Van will have a brand new 10" JVC float mount screen installed. This new radio features a double din chassis and an oversized float mount screen which fits in the factory location.

NOTE: This trim was the RV camper version which harness parts can differ from other Cargo / Passenger van versions. Please see the different sections below for parts based on your year and trim sprinter.

This video applies to Sprinter models for years:
*Dodge Sprinter 2007-2009
*Freightliner Sprinter 2007-2018
*Mercedes Metris 2016-up
*Mercedes Sprinter 2010-2018
This video also includes complete radio wiring and assembly, installation, and testing.

Click here to see the JVC 10" Radio unboxing and demo:
youtu.be/-EpLSjlfHpA

Click here to see the backup camera install video:
youtu.be/623reaH7rkM

Parts used in this install (Amazon Associate Paid Links):
*JVC KW-Z1000W 10" Radio: amzn.to/45pePS7
--Recommended in-dash 7": amzn.to/3SDoe5c
*Metra 99-6512 Dash Kit: amzn.to/3SqusDy
*(Select a radio harness options below based on your year, make, model, and trim Sprinter)
*Antenna Adapter will either be ONE of two options below:
-Metra 40-VW12 (earlier model Sprinters): amzn.to/2TMqRoZ
OR
-Metra 40-EU10 (later model Sprinters): amzn.to/2UKAuop
*HDMI / USB Flush Mount Adapter: amzn.to/2WAX5oJ
--Other versions of the flush mount adapter available:
-Dual USB Adapter: amzn.to/2URnTA0
-USB & HDMI: amzn.to/2WAX5oJ
-Single USB: amzn.to/3gGHkms
-USB & AUX: amzn.to/2SYXEGS


NOTE the Harness adapter changes based on the Sprinter Make, Model and Trim:
***Sprinter RV Camper***
*Dodge Sprinter 2007-2009: Metra 70-1784: amzn.to/2XKJATV
*Freightliner Sprinter 2007-2018: Metra 70-1784: amzn.to/2XKJATV
*Mercedes Sprinter w/ Pocket Below OR NO Radio 2010-2018: Metra 70-1784: amzn.to/2XKJATV
*Mercedes Sprinter w/ Full Radio 2010-2013: Metra 70-1784: amzn.to/2XKJATV
*Mercedes Sprinter w/ Full Radio 2014-2018: Pac RP4.2-MB11: amzn.to/3OyZS9V

***Sprinter CARGO***
*Dodge Sprinter w/ Pocket Below OR NO Radio 2007-2009: XSVI-1784-NAV: amzn.to/3uqVz9Q
*Dodge Sprinter w/ Full Radio 2007-2009: XSVI-9005-NAV: amzn.to/3Uz5FjF
*Freightliner Sprinter w/ Pocket Below Radio 2007-2013: XSVI-1784-NAV: amzn.to/3uqVz9Q
*Freightliner Sprinter w/ Pocket Below Radio 2014-2018: Metra 70-1784: amzn.to/2XKJATV
*Freightliner Sprinter w/ Full Radio 2007-2009: XSVI-9005-NAV: amzn.to/3Uz5FjF
*Freightliner Sprinter w/ Full Radio 2010-2013:
*Freightliner Sprinter w/ Full Radio 2014-2018: Pac RP4.2-MB11: amzn.to/3OyZS9V
*Mercedes Sprinter w/ Pocket Below Radio 2010-2013: XSVI-1784-NAV: amzn.to/3uqVz9Q
*Mercedes Sprinter w/ Pocket Below Radio 2014-2018: Metra 70-1784: amzn.to/2XKJATV
*Mercedes Sprinter w/ Full Radio 2010-2013:
*Mercedes Sprinter w/ Full Radio 2014-2018: Pac RP4.2-MB11: amzn.to/3OyZS9V

***Sprinter Chassis Cab***
*Dodge Sprinter NO Factory Radio 2007-2009: Metra 70-1784: amzn.to/2XKJATV
*Dodge Sprinter w/ Factory Radio 2007-2009: XSVI-1784-NAV: amzn.to/3uqVz9Q
*Freightliner Sprinter NO Factory Radio 2007-2018: Metra 70-1784: amzn.to/2XKJATV
*Freightliner Sprinter w/ Factory Radio 2007-2013: XSVI-1784-NAV: amzn.to/3uqVz9Q
*Freightliner Sprinter w/ Factory Radio 2014-2018: Pac RP4.2-MB11: amzn.to/3OyZS9V
*Mercedes Sprinter NO Factory Radio 2007-2018: Metra 70-1784: amzn.to/2XKJATV
*Mercedes Sprinter w/ Factory Radio 2010-2013: XSVI-1784-NAV: amzn.to/3uqVz9Q
*Mercedes Sprinter w/ Factory Radio 2014-2018: Pac RP4.2-MB11: amzn.to/3OyZS9V

***Sprinter Passenger***
*Dodge Sprinter w/ 13 Speaker System 2007-2009: XSVI-1788: ebay.us/IT2aMp
*Dodge Sprinter w/ 5 Speakers Full Radio 2007-2009: XSVI-9005-NAV: amzn.to/3Uz5FjF
*Dodge Sprinter w/ Pocket Below Radio 2007-2009: XSVI-1784-NAV: amzn.to/3uqVz9Q
*Freightliner Sprinter w/ 13 Speaker System 2007-2009: XSVI-1788: ebay.us/IT2aMp
*Freightliner Sprinter w/ 13 Speaker System 2010-2013:
*Freightliner Sprinter w/ 13 Speaker System 2014-2018: Pac RP4.2-MB11: amzn.to/3OyZS9V
*Freightliner Sprinter w/ 5 Speakers Full Radio 2007-2009: XSVI-9005-NAV: amzn.to/3Uz5FjF
*Freightliner Sprinter w/ 5 Speakers Full Radio 2010-2013:
*Freightliner Sprinter w/ Pocket Below Radio 2007-2013: XSVI-1784-NAV: amzn.to/3uqVz9Q
*Mercedes Sprinter w/ 13 Speaker System 2010-2013:
*Mercedes Sprinter w/ 13 Speaker System 2014-2018: Pac RP4.2-MB11: amzn.to/3OyZS9V
*Mercedes Sprinter w/ 5 Speakers Full Radio 2010-2013:
*Mercedes Sprinter w/ Pocket Below Radio 2010-2013: XSVI-1784-NAV: amzn.to/3uqVz9Q

*Disclosure: As an Amazon Associate I earn from qualifying purchases*
