Setting up an Equation for KCL @CircuitBread
Setting up an Equation for KCL  @CircuitBread
Uploaded July 2025 | Updated November 2026, 3 hours ago
If you ever want to solve for and understand circuits, you'll need to understand KCL or Kirchhoff's Current Law. With our Friend of CircuitBread, @DigilentInc , we did an overview of KCL and KVL and, in this short, Josh shows how to setup an equation for KCL. Once this is done, it's mostly just math but it is extremely helpful to have an intuitive feel for what should be happening. This will help with a "sanity check" to make sure that everything is working out as planned.
