Model
Brand
Rosewill
Model
RG430-S12
Series
Green Series
Spec
Type
ATX12V v2.3 & EPS12V v2.92
Maximum Power
430W
Fans
1 x Silent 120mm Golf Fan
PFC
Active
Main Connector
20+4Pin
+12V Rails
Single
PCI-Express Connector
1 x 6-Pin
SATA Power Connector
4
Modular
No
Efficiency
80%, Up to 85%
Energy-Efficient
80 PLUS Certified
Over Voltage Protection
Yes
Overload Protection
Yes
Input Voltage
100 - 240 V
Input Frequency Range
47 - 63 Hz
Input Current
10A @ 115V, 5A @ 230V
Output
+3.3V@24A, +5V@24A, +12V@33A, -12V@0.5V, +5Vsb@2.5A
MTBF
100,000 Hours
Approvals
UL, CUL, TUV, CB, FCC, ROHS
Dimensions
5.91" x 3.39" x 5.51"
Weight
3.85 lbs.
Features
Connectors
1 x 20+4-Pin Main Connector
1 x 4+4-Pin ATX12V/EPS12V Connector
1 x 6-Pin PCI-E Connector
6 x 4-Pin Peripheral Connector
4 x 5-Pin SATA Connector
1 x 4-Pin Floppy Connector
Features
Single 12V rail provide stable reliable power
Active power Factor Correction(PFC) provides clean and reliable power to your system
Universal AC input 90~264V automatically scans and detects
Black Coating Housing
Mesh sleeving on main cable for easier cable routing and better ventilation
Over Temperature/Current/Voltage/Power Protection, Under Voltage Protection, and Short Circuit Protection provide maximum safety to your critical system components
