Uploaded May 2023 | Updated September 2026, 3 weeks ago

---

For Rec 103

KiCad - kicad.org/download
Fritzing - fritzing.org/download
Falstad Circuit Simulator - falstad.com/circuit/circuitjs.html
TinkerCad - tinkercad.com


Time Stamps
00:00 Intro
00:31 Installing Kicad
01:33 Starting a new project
03:11 Basic Naviagation
03:45 Adding components
04:00 Resistor
04:20 Rotating components
04:23 Fliping components
04:43 Adding a battery
05:03 5 and 9 volt sources
06:05 Selecting Components
06:44 Capacitor
07:07 Op-amps
08:04 Duel Voltage Supply
08:21 Adding a ground
08:43 Wire tool
08:58 Dots for connection
11:30 Numbering components
12:25 Creating a basic schematic
13:36 Changing the value of a component
14:09 Exporting the schematic
14:23 Screenshot method
14:53 Greenshot Method
15:27 Kicad Method
16:23 Inkscape
18:26 Word / Google Doc
20:59 Fritzing
24:51 Falstad Circuit Simulator
25:25 Tinkercad
27:12 Potentiometer in kicad
