Uploaded August 2025 | Updated September 2026, 1 hour ago
Struggling with laser alignment on odd-shaped pieces? In this quick tip video, I’ll show you my go-to method for perfectly aligning one-off or prototype designs using nothing but paper or cardstock. No jigs, no fuss—just fast, reliable placement every time.
I use this technique when I cut unique shapes out of acrylic with my CO₂ laser and need to precisely align them for engraving on my UV laser. Since many of these are proof-of-concept pieces or short-run designs, I don’t want to spend time or materials building a dedicated jig. Instead, I cut a disposable template out of paper or cardstock to act as a placement guide. It’s quick, cheap, and dead accurate.
🎯 Perfect for:
- Prototyping new designs
- One-off engravings
- Saving time on alignment
- Mixed laser workflows (CO₂ + UV)
🔧 Tools Used:
- xTool P2 CO2 Laser
- Hao-Tian 5W UV Laser Engraver
- LightBurn Laser Software
👍 Like + Subscribe for more LightBurn magic, beginner-friendly laser tips, and tutorials.
The Tinkerverse - Education and coaching for your laser journey
---------------------------
facebook.com/thetinkervers
instagram.com/thetinkerverse
https://linktr.ee/thetinkerverse
