Proteus Simulation - Interfacing MAX7219 dot matrix display with Arduino. Circuit schematic diagram and Arduino code at:
simple-circuit.com/interfacing-max7219-led-dot-matrix-display-arduino

DIY hardware circuit video:
youtu.be/dvUqeVZ5KEQ

Required components:
* Arduino board
* MAX7219 LED dot matrix display module
* External 5V, 1A source
* Jumper wires
