Proof-of-Concept: Keyboard Buttonboard for PIU FX Model Cabinets @dj505
Proof-of-Concept: Keyboard Buttonboard for PIU FX Model Cabinets  @dj505
Uploaded March 2022 | Updated November 2026, 3 hours ago
A fully functional QMK-powered custom mechanical keyboard slapped onto a Pump it Up FX model arcade cabinet.
Photos of the build/wiring at imgur.com/a/pump-up-fx-custom-buttonboard-GhewL0m

Q: What switches are you using?
A: The cheapest knockoff MX Reds I could get my hands on

Q: Why does the layout suck?
A: I could only fit 11 keys side by side since the amount of open space under the buttonboard is smaller than what you'd expect. There's only a few millimetres of clearance on either side.

Q: Why?
A: Why not?

Q: Will the design be public?
A: Eventually. I'm not happy with the current version and need to make some adjustments. Keep an eye out here for an eventual link!
