Uploaded October 2020 | Updated September 2026, 2 weeks ago

---

Video showing the features, the ports and the hardware connections to the Pinscape All in one.

Just a small correction, when describing the Diode. I mixed up the terms, The side with the grey bar is called cathode. The diagram is correct.

SECTIONS:
Powering up the AIO: 06:22
Buttons: 08:14
Shaker Motor: 09:44
Contactors: 10:38
Strobes: 11:37
Arnoz's 12v flashers 12:20
DIY Led 5 flash bar: 13:57
Oak Micros Resistors board: 15:18
Beacon: 16:57
Oak Micros plunger kit: 17:28
Chime unit: 18:41
Oak Micros Pinscape Lite: 20:31
Testing in the Cab : 22:13

The Pinscape AIO and Fuse board, plunger kit and resistors board i mentioned in the video are available from Oak Micros. vpforums.org/index.php?showtopic=43173

The 12V flashers LED are from Arnoz's shop : shop.arnoz.com/en/pincab/28-flash-with-plug-165cm-solded-wire.html

PDF of this guide: vpwiki.net/images/b/bf/Pinscape_AIO_connection_guide_by_Major_Frenchy.pdf

The Virtual Pinball Discord Chat : bit.ly/virtualpinball

Virtual Pinball WIKI: vpwiki.net

Virtual Pinball Parts list: vpwiki.net/Parts
