Pilot Rc 1/5 F-16 Fighting Falcon, On board footage. Available at Banana Hobby
Pilot Rc 1/5 F-16 Fighting Falcon Flight Review
Purchase Link: bananahobby.com/12-ch-pilot-rc-scheme05-1-5-f-16-3-06m-120-5-inch-composite-rc-turbine-jet.html
Full composite construction, lightweight and strong
Two piece wing and two piece full flying stabiliser, both fully removeable
Two piece wing and two piece full flying stabiliser, all for easy transport
Easily detachable rudder for easy transport
Two piece fuselage, with the split strategically placed to allow daily removal of tail section for easy transport to and from the flying field
Easily detachable ventral fins, held in place with just two screws
Painted outside the mold so no seam lines
Specifications
Wingspan2115mm (83.3in)
Length3060mm (120.5in)
Weight22.1kg (46.8 lb) with Vector Thrust pipe
Included Hardware (ARF)
Complete air frame (including fibreglass control horns)Carbon fibre wing-tubes, integrated into each wingServo extension leadsFixed Dual wall thrust pipe (for 200-320N turbines)Fuel tank (6600ml) and UAT (250ml)Pre-prepared pushrods with ball linksPre-glued control horns
Optional Extras
Pilot-RC electric retracts and electric brakes specific for this modelVector thrust pipe (Elevator and Rudder axis)1600ml smoke tankSmoke system (includes kevlar tank, smoke pump, injection pipe and fuel tubing)Scale cockpit (minus pilot)
Required Hardware (ARF to RTF)
Engine: 200-320NServos: (x9 + 2 optional)
x5 super high torque (minimum 35kg) // Uses x1 per aileron, x1 per elevator, x1 on rudder
x4 middle size servo, 35 x 15 x 30mm (minimum 16kg) // Uses x3 for gear doors and x1 for steering
+2 super high torque (minimum 35kg) if installing vector thrust pipe
Also requires all the usual accessories such as transmitter, receiver, batteries, powerbox and possibly other small accessories
Recommended Hardware
Servos: Pilot-Rc PW48AH (48Kg – 0,10s at 8,4v)Servos: Pilot-Rc PW16AH (16Kg – 0,057s at 8,4v)
Build Info
