Uploaded April 2017 | Updated September 2026, 2 weeks ago

---

Taking a look at a new pcb jig today. This one I feel is going to be great for any smaller PCB's but especially mobile phone PCB's.

High Temperature PCB Jig/Fixture - goo.gl/UK2mmk

**THE STUFF I USE**
Solder :- Multicore 60/40
Solder Paste :- Amtech NC-559-V2-TF
Switch Cleaner :- Servisol Super10
Freeze Spray :- Servisol Freeze It
Screwdrivers :- Wera & Knipex
Microscope :- GT Vision GXM-XTL3TV1
Pliers & Cutters :- Knipex
Solder Station :- Pace ST50
Rework Tweezers :- Pace MT-100 MiniTweez
Hot Air Station :- 858D
General Tweezers :- Lindstrom & Ideal-Tek
Multimeters :- Keysight U1252B & U1253B
Precision Multimeters :- Keysight 34465A & Keithley 2015THD
PSU's :- TTi QL355T & Keithley 2230G-30-1
Multifunction Tester :- Fluke 1653B
Electronic Load :- Maynuo M9710
Oscilloscope :- Rigol-DS2200
Spectrum Analyser :- Rigol-DSA805-TG
Signal Generator :- Rigol-DSG4162 & DG1012
Frequency Counter :- Racal-Dana 1998
Variac :- Carroll & Meynell 8A
Ultrasonic bath :- GT Sonic (3Litre)
