This is the second of the series for the waveguiding structures using the periodic band gap materials (The first one is at: youtube.com/watch?v=gZkFVco4kL4).
Here, two simultaneous simulations are shown. In the right one, both excitations are in-phase (cosine-cosine) whereas in the left, the excitations are out of phase by 90 degrees (sine-cosine).
Originally, this was inspired by the following video:
youtube.com/watch?v=O-6l0bvAda0
Guiding EM waves via periodic structure. The frequency of operation is 11.085 GHz. The relative dielectric permittivity of the square blocks are 11.56 and the ambient medium is air. Each block is 3.5 mm x 3.5 mm.
The main reference is the below dissertation:
Marcelo Bruno Dias, "Estudo da Propagação de Ondas Eletromagnéticas em Estruturas Periódicas". Graduation Dissertation - Electrical Engineering Course, Universidade Federal do Pará (UFPA), Belém, Pará Brazil, 2003.
More details can be found in their lab web site:
www.lane.ufpa.br/publicacoes.html
Also see below:
Half Wavelength Dipole Antenna Radiation
youtube.com/watch?v=Wllxhuo9iPk
Oblique Plane Wave Reflection From Half Space
youtube.com/watch?v=0-koW8jm8Pw
Radiation from a Circularly Tapered Dielectric Waveguide
youtube.com/watch?v=EXvdruxTDKk
Right Hand Circular Polarization (RHCP) Animation
youtube.com/watch?v=jY9hnDzA6Ps
Linear Polarization Animation
youtube.com/watch?v=oDwqUgDFe94
Left Hand Elliptical Polarization (LHEP) Animation
youtube.com/watch?v=KZz25bmTWXo
Standing Wave Pattern (SWR) Animation
youtube.com/watch?v=s5MBno0PZjE
Electromagnetic Propagation of UWB Short Pulse in Random Medium
youtube.com/watch?v=qpDQ44F4Qks
