Yellow and orange bars create a pantograph.
Input: Cyan (or pink) crank.
Output: The other crank. It rotates at the same input velocity but in opposite direction.

Link Dimensions are shown at the bottom right of the video.
Distance between fixed revolute joints = 9

Line connecting centers of fixed revolute joints of the cranks is parallel to sliding direction of green slider.
Length ratio of the Cyan and pink cranks: 1
Light gray gears do not belong to the mechanism. Their appearance aims to show transmission ratio of -1 between the cranks.
