Heres an overview of the Black Bolt XBR220. This is generally how we like to build the quad. One note, the battery connector can come out the back or the side. Personally I prefer the side as it interferes less with the battery (as you see at the end of the video). The VTX can also be placed in different areas, such as ziptied on top of an esc.
Link to sandwich tutorial: youtu.be/XihX4Q-az74
Scorpion Lipoly Lock Strap (Medium)
Wide angle lenses: surveilzone.com/search/index?keywords=1.8mm+lens&category=0
To use the smaller pancake lens you will have to buy the shorter lens mount in order to properly focus, or trim down your current lens mount. surveilzone.com/lens-mount-and-ring-for-board-camera-pa1224
