Uploaded February 2017 | Updated September 2026, 55 minutes ago

---

Stress test article - retroresolution.com/2015/11/29/overclocking-and-stability-testing-the-raspberry-pi-2-part-4-sd-storage-testing

Check your Pi's CPU temperature - vcgencmd measure_temp

Check your pi's current CPU speed - cat /sys/devices/system/cpu/cpu0/cpufreq/scaling_cur_freq



--------------------



Here are all the overclock settings I found. I have to say the no fucks given setting made a BIG difference in games that I was getting lag in.

NOT ALL PI'S are created equal so you may not be able to use the extreme or the no fucks given overclock.


BASE Overclock 1.3ghz GPU 500mhz SDRAM 500

arm_freq=1300
gpu_freq=500
core_freq=500
sdram_freq=500
sdram_schmoo=0x02000020
over_voltage=2
sdram_over_voltage=2


HIGH Overclock 1.35hz GPU 500mhz SDRAM 500

arm_freq=1350
gpu_freq=500
core_freq=500
sdram_freq=500
sdram_schmoo=0x02000020
over_voltage=2
sdram_over_voltage=2


EXTREME OVERCLOCK 1.4GHZ GPU 520mhz SDRAM 520mhz

arm_freq=1400
gpu_freq=520
core_freq=520
sdram_freq=520
sdram_schmoo=0x02000020
over_voltage=2
sdram_over_voltage=2


AND FINALLY WE HAVE THE NO F&$%* GIVEN OVERCLOCK
WARNING THIS WILL NOT WORK ON 99% OF THE PI 3's OUT IN THE WILD.

Some people have gotten lucky enough to get a pi with the ability to overclock this high

arm_freq=1500
gpu_freq=550
core_freq=550
sdram_freq=600
sdram_schmoo=0x02000020
over_voltage=3
sdram_over_voltage=3
