here's how to setup ortho remote as a BLE-MIDI device.
online guide: https://teenage.engineering/guides/or-1#ble-midi
order here: https://teenage.engineering/store/ortho-remote/

---

further configuration:
- compose sysex message in hex editor (e.g. hexfiend.com/)
- save as .syx
- send to remote over BLE MIDI (e.g. snoize.com/sysexlibrarian/)

sysex spec:
strt | TE or1 | cmd addr values | end
-----|--------------|------------------|----
F0 | 00 20 76 02 | xx xx xx ... | F7

cmd
00 write
01 read

addr setting default
00 midi channel 0
01 midi cc 1
02 midi cc abs (0 or 1) 1
03 midi note 60
04 midi velocity 100

values
write list of values for consecutive addresses after addr
read number of consecutive addresses to read after addr (0 = read all)
- response msg can be used to write those values back

examples
F0 00 20 76 02 00 01 0e F7 set send cc 14
F0 00 20 76 02 01 00 00 F7 read all


sysex identity response

strt | TE or1 | ver color reserved | end
---------------|----------------|----------------------|----
F0 7E xx 06 02 | 00 20 76 02 00 | xx xx xx xx | F7

colors
blue 0
green 1
orange 2
red 3
black 4
grey 5
yellow 6
white 7
