In this video, we will install OpenWRT on the Aruba AP-105 and configure it as an AP. For the Aruba AP-105, we can't just simply install the firmware via the TFTP because there is a checksum or signature verification of the firware by bootloader (or uBoot). We need to make a dump of the current rom, add the custom uBoot and write it back to the SPI NOR Flash chip of the AP-105 in order to install OpenWRT.
The the the Aruba AP-105 is using the SPI NOR Flash from Macronix. We will need a 16 pin test clip in order to establish the SPI connection between the SPI Flash to PC/Raspberry Pi.
Video timeframe:
00:00 - Intro - OpenWRT on the Aruba AP-105
00:40 - Disassemble the Aruba AP-105
01:46 - The Macronix SPI Flash & 16 pin test clip
02:30 - Connection diagram AP-105 SPI FLASH to Raspberry Pi GPIO
03:11 - Enable SPI interface on Raspberry Pi
04:16 - Create a full dump of the ROM, add custom uBoot and write back to SPI FLASH
07:14 - Configure TFTP server with tftp64
07:40 - Download & prepare the OpenWRT firmware
08:14 - Establish the Serial console connection with Putty (if you have one)
08:40 - Enter recovery mode & Install OpenWRT via TFTP
11:50 - Setting root password & Check LAN IP
12:30 - Acess the AP-105 running OpenWRT LuCI Web Interface
13:13 - Configure a static IP for the AP-105
15:15 - Setup WiFi
15:56 - WiFi speedtest with Aruba AP-105 running OpenWRT
16:26 - WiFi speedtest with bmon and CPU usage overview
Resources:
Aruba AP-105 OpenWRT TOH - openwrt.org/toh/aruba/ap-105
SPI Flash on AP-105 forum post - forum.openwrt.org/t/aruba-ap-105-spi-flash-rpi
TFTP64 - pjo2.github.io/tftpd64
Custom uBoot for AP-105 - github.com/chunkeey/u-boot-ap105/releases
Good luck!
