Here's my latest frame. The Bando Basher. A 3" low profile top deck mount.
Designed to house the Caddx Turtle or Runcam split mini. (Any 19mm camera) with dual 20x20 stack and the option of 20mm top deck height (23mm build height) or 15mm height (18mm build height) which I'm flying.
All the arms are removable and identical so breaking an arm is easy to replace via 2 screws, without effecting the rest of the hardware. Both braces are removable, the front being integral to design but the rear optional. Im yet to test without the rear brace.
The frame weight with hardware is about 54g. 2mm thick top, bottom, cam pod and braces with 3mm thick arms.
Flying this today with..
Hglrc f440
Frsky xm+
Tx20 v2 vtx
Diatone (Sunnysky) edge 1408 4000kv (rubbish motors Tbh)
Swift micro
Gemfan 3052 props
Cnhl 650 4s and Gnb550 3s.
