NanoPi NEO Plus2 is a very compact yet powerful Single Board Computer designed to function as a NAS, Pi-hole, a small firewall gateway and much more.

Full Article Review: bit.ly/2Hyvwna

Product Buy Links:
1) Board: bit.ly/2XYdSOB
2) Case: bit.ly/2UEsAYY
----------------------------------------------------------------------------------------------------------
Main Specs:

SoC: Allwinner H5 (64-bit)
CPU Number of Cores: Cortex-A53 Quad-Core (4) x Cortex-A53
Frequency: 1.5GHz
Memroy RAM: 512MB or 1GB DDR3
Internal Storage eMMC: 8GB
MicroSD Slot: MicroSD*1 for external storage up to 128GB
Connectivity Ethernet: Gbps Ethernet, RTL8211E-VB-CG chip
WiFi: 802.11b/g/n
Bluetooth: 4.0 dual mode
Antenna: IPX Connector*1
Audio: Input/Output: 2.54mm pitch 5 pin-header
USB: USB 2.0*1: USB 2.0 Host Type A
USB pin header*2
MicroUSB*1: Power input(5V/2A)
Pin-header GPIO 1:
24Pin, 2.54mm pitch double-row pin-header containing UART, SPI, I2C and IO

GPIO 2:
12Pin, 2.54mm pitch pin-header containing USB, IR receiver, I2S and IO
Serial Debug Port: 2.54mm pitch 4pin-header
LED Power LED(Red)*1
System LED(Green)*1
