Polygraphica have available for immediate sale the following MPS EF520, 14 (yes, fourteen) Station Printing Press.

The machine can be configured to almost any packaging process currently available. It has recently been manufacturing Lottery Scratch Cards.

MPS EF520 – 14 STATION - LABEL & PACKAGING PRESS
Year of manufacture: 2016

Web width: 520mm
Print width: 510mm
Print & die repeat: 12-25”
Substrate thickness: 15-450micron
Unwind and rewind: 1.270mm
11 x EF servo print stations
Print sleeves
Chills
2 x EXL packaging servo print stations
Print sleeve
Chills
Lean inking
14 x GEW Rhino UV
3 x hot air systems
Double die stations QCD
Multi laminating unit
SA lamination
UV lamination
CF lamination
Chiller
2 x turn bars
2 x BST web inspection
Web cleaner: Teknek
Tidland slitting, scissor type
Auto print control APC x 11
M2M auto register
iControl
Advanced job memory

General
Machine can be seen in production
Availability: immediate
Location: Europe
Polygraphica Reference: V56995

If you require further details on the MPS EF520, please email sales@polygraphica.com or telephone +44 1924 200444.
