Discover Infineon’s Power Suite training kit powered by PSOC™ Control C3, featuring a totem‑pole PFC (Power Factor Correction) design and an integrated software and GUI solution for industrial power applications.
In this video, Massimo Paglia, Product Application Engineer for Industrial Microcontrollers at Infineon, introduces a scaled‑down, safe training kit that replicates a high‑voltage interleaved totem‑pole PFC. The system operates in a galvanically isolated environment, using a low‑voltage AC input while maintaining the same control behavior as real high‑voltage designs.
Timestamps:
0:00 Introduction & demo overview
0:08 Power Suite with PSOC™ Control C3
0:13 Training kit hardware + software overview
0:20 Totem‑pole PFC hardware explained
0:25 Interleaved PFC training kit
0:32 High‑voltage PFC replicated safely
0:37 Scaled‑down design (factor 10)
0:40 Galvanic isolation via AC transformer
0:46 AC input: 23 V RMS
0:49 DC output: 40 V
0:53 DC loop & current visualization
0:56 Control running on PSOC™ Control C3
1:06 Load change & voltage regulation demo
1:20 Power Suite GUI overview
1:24 Oscilloscope functionality
1:32 Capturing internal variables
1:36 PMBus data streaming
1:40 Sending PMBus commands
1:47 Turning system on/off & changing voltage
1:54 Where to find more information
2:04 PSC3‑PFC1 kit reference
