Uploaded October 2016 | Updated September 2026, 2 weeks ago
berkeleynucleonics.com/model-745-oem
Berkeley Nucleonics' Model 745-OEM is a compact digital delay generator intended for use in embedded OEM applications. 4 channel and 8 channel options are available. Delays up to 10 seconds can be programmed with 0.25ps resolution, and channel to channel jitter is less than 25 ps rms. One T0 channel is used to time reference all delayed pulse outputs. MCX outputs deliver up to 5V, 2 ns under 50Ω. Pulse amplitude and width are adjustable on each output channel.
berkeleynucleonics.com/model-745-oem
Berkeley Nucleonics' Model 745-OEM is a compact digital delay generator intended for use in embedded OEM applications. 4 channel and 8 channel options are available. Delays up to 10 seconds can be programmed with 0.25ps resolution, and channel to channel jitter is less than 25 ps rms. One T0 channel is used to time reference all delayed pulse outputs. MCX outputs deliver up to 5V, 2 ns under 50Ω. Pulse amplitude and width are adjustable on each output channel.
