Uploaded July 2021 | Updated September 2026, 3 weeks ago
-- Expand for more info --
In this video, I connected my Commodore 1571 disk drive #8 to my MiSTer FPGA via the external IEC adapter. I loaded the C64 core and used Maverick to copy Alpharay.d64 (40 tracks) to a 5 1/4 disk for the Commodore Plus/4 computer. I loaded the Alpharay disk from my 1571 disk drive on the MiSTer Commodore Plus/4 core.
---------------------------------------------------------------------------------------------
Download Alpharay: psytronik.itch.io/alpharay
*NOTE: This game is PAL only.
*CONVERTING ALPHARAY DISK IMAGE:
Please note that this is a 40 track disk image so in order to convert it back onto a real floppy disk you will need to use a transfer system that supports 40 track disks.
---------------------------------------------------------------------------------------------
Product Description from the web page: antoniovillena.es/store/product/commodore-1541-sd2iec-adapter-for-mister
Note: Only for DB9 MiSTer (SLIM, DRIVE, and MINI). For official MiSTer please wait for other sellers.
This device interconnects the MiSTer FPGA to a real Commodore disk drive. Also compatible with drive emulators like SD2IEC. To provide power to SD2IEC there are two edge connectors: user port and tape port.
Can be connected directly to the DB9 port, but optionally I sell with a DB9 extender cable.
---------------------------------------------------------------------------------------------
You can buy a Complete MiSTer Setup from these vendors:
- SNAC2IEC: ultimatemister.com/product/mister-snac-iec-c64/?fbclid=IwAR0opkFv2cf4fwIyPSJH7MFP1qedPO0dMdG2-dhcdAtVcWjeLMIiHED6Vhg
- misteraddons.com
- antoniovillena.es/store
- ultimatemister.com
Mister FPGA Wiki Project:
github.com/MiSTer-devel/Main_MiSTer/wiki
Mister Forum discussion: misterfpga.org
Sorgelig's MiSTer Cores: github.com/MiSTer-devel
MiSTer Facebook page:
facebook.com/groups/1870135613286506
#MiSTerFPGA #CommodorePlus4 #Commodore1571 #Alpharay
