Uploaded September 2010 | Updated September 2026, 3 weeks ago
So with 24 hours before MicroPalooza, I decided I should make a laser scanner effect for a little eye candy. The laser is a cheapo Laserworld CS-400RGB that I had already. I hacked in an Atmel ATXMega16A4 using one ADC channel to digitize the audio and the two DAC channels to drive the X/Y output to the scanner. The output is through a standard ILDA interface.
Since the laser is TTL blanking only, I just connected the ILDA RGB pins to IO's on the XMega. I didn't have much time left to write the software after bodging everything together, but I was able to implement a standard oscilloscope as well as a circular one and some sine wave tricks.
I only used about ~7K of Flash in the XMega (most of that for tables).
Amazingly enough it ran all night and worked like a charm. I need to program more displays, but it's fun having real time response without a big old PC running the show. (and all solid state-- no extra spinning mirrors or motors or whatnot).
The galvos are really slow/crappy, so all the waveforms appear a bit 'filtered' (rounded edges), but it still looked pretty cool. The live chiptunes worked great for input.
The artist's name is "Mechlo" and the song is "Bad Vision".
