Here is the complete step-by-step workflow to create a crisp, professional **Wireframe Render** in **Maya 2023** using Arnold.
---
### Method 1: The Arnold `aiWireframe` Shader (Most Common & Flexible)
*This method generates a clean wireframe pass over a base material, giving you full control over wire color, edge density, and fill color without affecting your geometry.*
1. **Create the Wireframe Material**
* Open the **Hypershade** (`Windows - Rendering Editors - Hypershade`).
* In the Create tab, search for **`aiWireframe`** and click it to create the node.
* Select the `aiWireframe` node and adjust its settings in the **Attribute Editor**:
* **Edge Type:** Set to **Polygons** (or *Quads* depending on how clean you want the topology layout to look).
* **Fill Color:** Set to a neutral color (e.g., dark gray or off-white) if you want a solid base under the wires, or keep it black.
* **Line Color:** Set to white (or any high-contrast color like green or light blue).
* **Line Width:** Keep it thin, around `1.0` to `1.5` pixels so dense topology doesn't turn solid black.
* **Raster Space:** Set to **Screen Space** (keeps line thickness consistent regardless of camera distance) or **World Space** (line thickness scales naturally with 3D space).
2. **Apply the Shader**
* Select the objects in your scene.
* Right-click the `aiWireframe` material in Hypershade and select **Assign Material to Selection**.
3. **Render**
* Open the Arnold RenderView (`Arnold - Open RenderView`) and hit **Play**.
---
### Method 2: Non-Destructive Wireframe Overlay via Render Setup
*If you want to create a dedicated Wireframe render pass while leaving your main materials untouched:*
1. Open the **Render Setup** window (`Windows - Rendering Editors - Render Setup`).
2. Click **Create Layer** (+) and name it `Wireframe_Pass`.
3. Right-click `Wireframe_Pass` - **Create Collection** (e.g., `col_AllGeo`).
4. Select your objects in the Outliner and click **Add** in the Collection Properties panel.
5. Right-click `col_AllGeo` - **Create Material Override**.
6. Middle-mouse drag your `aiWireframe` shader into the **Override Material** box.
7. Toggle the **Eye Icon** on the `Wireframe_Pass` layer to preview and render.
---
### Method 3: Viewport 2.0 Quick Playblast (For Fast Portfolios/Previews)
*If you need a quick, stylized wireframe capture without waiting for Arnold tracing:*
1. In the Viewport menu, go to **Shading** - enable **Wireframe on Shaded**.
2. Go to **Show** - turn off **Grid**, **Lights**, and **Cameras** to clean up the frame.
3. Select **Display - Render Settings** and switch the Renderer to **Maya Hardware 2.0**.
4. In Render Settings - **Maya Hardware 2.0** tab:
* Set **Anti-aliasing** to **Enabled** and crank **Multi Sampling** to `16` for smooth lines.
5. Hit Render or perform a **Playblast** (`Window - Playblast`).
---
### Pro-Tip: Combining Wireframe + Clay (The Portfolio Standard)
To achieve the popular reel showcase look (a clay model with semi-transparent wireframe edges):
1. In the Hypershade, create a standard **`aiStandardSurface`** (clay base).
2. Create an **`aiWireframe`** shader.
3. Create a **`mixShader`** node.
4. Plug the clay material into **Shader 1** and the `aiWireframe` into **Shader 2**.
5. Adjust the **Mix Weight** slider to composite the wireframe neatly over your clay sculpt!
