Make this engineers square in your own home. I used machinery, but you don't have too. This item can be made with just a steel rule, hacksaw, electric drill, hammer and some solid rivets (or nails). Learn how to model this in CAD youtu.be/U0rTvkr8gQ0

Download 3D CAD model here: a360.co/3Fe1lAG
Download 2D CAD drawing here: a360.co/3QXFdgg
Download PDF plans here: a360.co/4bFBAVV

Machinery I used were:
Herless combination milling machine
Waldown drill press
GMF senior grinder with belt attachment
Herless tool and cutter grinder

#DIY #Engineers #Square
