This aspect of the Tesla Circuit is interesting in that the distance between the spark gap SIGNIFICANTLY affects voltage output.
Now Contemplate our planets Electric gradient from surface to ionosphere. This circuit from Nikola Tesla, seems to model things very well.
The circuit seems to auto regulate important edance and voltage difference is tunable via increasing the length of the shunted side bars, to see more energy on the shunted side, as well as increasing the spark gap distance increases the output voltage. Why would the output voltage be lower with the gap smaller? Why would it auto up regulate from 2kV to 10kV? Is this to be expected? Forgive my ignorance of Transformers, but I would have anticipated it would produce a fixed output voltage.
Very Best Regards,
Jim
