Uploaded July 2026 | Updated November 2026, 13 hours ago
It's been 10 years since the harmonàig was developed. I think it's time for a deep dive into understanding how it can make modular more musical.
The harmonàig has always been one of the most musically powerful and compositionally focused modules in the Instruō range. It is a performance quantiser capable of transforming a simple CV sequence into rich, four-voice harmonic movement.
This new video offers a refined overview of the module's features and functionality, before diving into its implementation of musical harmony.
The second half introduces some music theory fundamentals, but more importantly demonstrates just how much can be achieved without needing to understand any of it (although it is fun!).
The harmonàig provides a framework for exploring chord progressions, patching harmonic relationships within a Eurorack system, and making complex musical structures feel intuitive and playable.
The harmonàig has remained a core part of the Instruō range for the past 10 years thanks to your continued support.
00:00:00 - Instruōduction
00:01:34 - What's to come
00:04:52 - Quick overview
00:11:30 - harmonàig overview
01:06:12 - Chord theory
01:36:07 - MODE theory
02:00:30 - Ouststruō
