Inside a 20 kV 2 A High Voltage Diode + Voltage-Balancing Issues in Series Connected Diodes @HVE
Inside a 20 kV 2 A High Voltage Diode + Voltage-Balancing Issues in Series Connected Diodes @HVE
Uploaded November 2025 | Updated September 2026, 2 hours ago
In this video, I open a 20 kV, 2 A high-voltage diode to show what’s inside and explain the main challenges of using diodes in series—including static voltage balancing, dynamic voltage imbalance during fast transients, temperature effects, and overvoltages caused by mismatched reverse-recovery currents.
