Uploaded July 2021 | Updated September 2026, 1 week ago
For more information, visit keysight.com/find/mod-usb
0:00 Introductions & trademarks
0:53 Agenda
1:15 Technology overview & timeline
2:41 Architecture overview
3:45 Differences between testing USB 3.2 x 1 vs USB4
7:18 Insertion loss budgets
8.44 Compliance test points
9:44 Proposed transmitter test setup
14:12 Return loss tests
14:57 Topology
18:52 Proposed receiver test setup
23:00 Solutions Summary
USB4 was released in 2019 and based on the Thunderbolt 3 protocol. USB4 adds significant complexity by doubling the data rate of USB 3.2 x2. It is expected that USB4 will be adopted in many devices. These faster signals require ultra-low noise test instruments. We will review the latest information about the USB4 test specification, challenges with implementing USB4, and Keysight test solutions.
