How to run an AirShaper simulation
Hi, and welcome to AirShaper, the cloud-based simulation platform for external aerodynamics.
In just three easy steps you can obtain all the data & insights you need to understand and improve the aerodynamics of your design.
Fixed wing drone
Step 1 - The Set Up
Start a new project and select the required accuracy. If you’re just exploring initial concepts or simple shapes, a concept simulation will do. If you’re working on the final details or a very complex 3D model, our ultimate simulation is the best choice.
Give the project a name and simply drag & drop your 3D file into AirShaper. By the way, AirShaper is capable of working directly with open surface models. So there is no need to spend weeks to make your 3D model watertight.
On the setup page, first, choose your simulation type. This drone, for example, is above the ground and moving. Fill in the velocity and rotate the model if needed. Finally, let us know the units of your 3D model and if needed, add a scale factor. That’s all there is to it for the setup!
Simply fill in your details on the payment page and submit the simulation.
STEP 2 – The Cloud Simulations
Our automated algorithms will now automatically build a virtual wind tunnel around your 3D model and analyze the aerodynamics. And because it’s a cloud platform, you don’t need any software or hardware and we can use high-performance computing to deliver fast and accurate results.
STEP 3 - The Results
Once the simulation is finished, a full simulation report will be in your mailbox.
You can also view the 3D flow results directly in your browser. Look at pressure, for example, to find sources of drag, analyze streamlines to understand vortex structures and even get insights into which areas are generating wind noise!
And it that is not enough, you can download the full flow results to perform your own post-processing.
-----------------------------------------------------------------------------------------------------------
The AirShaper videos cover the basics of aerodynamics (aerodynamic drag, drag & lift coefficients, boundary layer theory, flow separation, reynolds number...), simulation aspects (computational fluid dynamics, CFD meshing, ...) and aerodynamic testing (wind tunnel testing, flow visualization, ...).
We then use those basics to explain the aerodynamics of (race) cars (aerodynamic efficiency of electric vehicles, aerodynamic drag, downforce, aero maps, formula one aerodynamics, ...), drones and airplanes (propellers, airfoils, electric aviation, eVTOLS, ...), motorcycles (wind buffeting, motogp aerodynamics, ...) and more!
