RimstarOrg | How to Make Capacitors - Low Voltage Homemade/DIY Capacitors @RimstarOrg | Uploaded 12 years ago | Updated 3 hours ago
A variety of info on how to make low voltage capacitors. I start with demonstrating making a temporary flat plate capacitor, then a spiral capacitor and then a salt water jar capacitor, sometimes called a salt water Leyden jar. Then I talk about capacitance and the unit farad and show the difference between microfarad, nanofarad and picofarad. Next, using the formula for a flat plate capacitor as a base I discuss the affect of capacitor area and distance between the plates on the capacitance. I also go over the dielectric constant, sometimes called the relative permittivity, and end with the formula for a cylindrical capacitor. All this is to help in designing capacitors. I then show how to use a meter, DMM, to measure capacitance. That's followed by two sample variable capacitors and then a discussion about breakdown voltage, or dielectric strength.
Watch the "How to Make High Voltage Capacitors - Homemade/DIY" video here:
http://youtu.be/MPD7skZ8OSo
To make higher capacitance capacitors, for around 62 microfarads see my "How to Make an Electrolytic Capacitor" video here:
http://youtu.be/ml2TdQ2_2mk
And for even higher capacitance, 580 microfarads, see my "How to Make a High Capacitance Electrolytic Capacitor" video here:
http://youtu.be/lmVVdV8wuB0
For details about my work with Barium Titanate capacitors, see:
http://rimstar.org/materials/dielectrics/barium_titanate_capacitor_batio3.htm
For examples of how I've figured out the dielectric constant of various materials, see my webpage here:
http://rimstar.org/materials/dielectrics/dielectrics.htm
3D capacitor animation done using Blender 2.63.
To follow me on Twitter:
twitter.com/#!/RimStarz
http://rimstar.org
