Learn how to disassemble the dispenser on a Kenmore 795-series French door refrigerator model 795.72052110.

Unplug the refrigerator before beginning disassembly.

Remove the funnel by squeezing the sides and pulling it down.

Insert a screwdriver behind the user interface and pry the bottom of the interface loose.

Disconnect the user interface wire harnesses.

To access the rest of the dispenser components, remove the 3 screws in the dispenser housing cover. Pull out of the bottom of the cover and remove it.

When you reassemble the dispenser, make sure that you don't pinch the wiring.
