How to Connect NI DAQ Accessories to NI Multifunction I/O Devices @NIApps
How to Connect NI DAQ Accessories to NI Multifunction I/O Devices  @NIApps
Uploaded September 2025 | Updated November 2026, 3 hours ago
Watch full series at youtube.com/playlist?list=PLbCk9hRe-ziGe04skuLyrEnt8h2wgxeHJ

In this step-by-step tutorial, learn how to properly connect two NI #DAQ accessories to a PXIe Multifunction I/O board using the SHC68-68-EPM shielded cable and verify your setup using the NI Hardware Configuration Utility. This video walks you through the physical setup and connection process for the following commonly used accessories:

✅ SCB-68A: A versatile, shielded connector block that offers flexible wiring options for custom signal routing.
✅ BNC-2120: A BNC-style connector block designed for easy access to analog and digital signals.

Learn more at bit.ly/4n3bvoE and bit.ly/4mqgAWR
