I converted my EMAX Nanohawk to a toothpick-style drone and increased the prop size to 40mm. It’s super fun! I call it my "NanoBug"! Parts list and links below.
You can also follow me on Instagram to see what I'm up to. I post pretty often these day:
instagram.com/mrshutterbug
Want to help support this channel? Simply bookmark any of these links and use them when you shop for FPV gear. Each time you make a purchase, they will give me a small commission. It is totally free for you and it helps me get parts for future projects. Thanks!
Banggood: bit.ly/2OVcf1r
BETAFPV: bit.ly/betafpv-shutterbug
GetFPV: bit.ly/2Ot4q2K
Heli-Nation: bit.ly/heli-nation
Here's my review of the EMAX Nanohawk, in case you haven't seen it:
youtu.be/wnb2eKkTGa8
STL Files:
thingiverse.com/thing:4779696
Parts List (affiliate links, when available):
- EMAX Nanohawk BNF drone: bit.ly/3rxQJkt
- EMAX 300mah 1S batteries: bit.ly/3qxJo2Q
- BeeBrain V2 Canopy: bit.ly/37qLvMd
- HQ 40mm 2-blade props: bit.ly/3vjbz9B
- Reny M2 12mm screws (cut to length or use metal screws): bit.ly/3au3KD5
- Replacement Nanohawk Frame: bit.ly/396IVir
PowerPlay DVR used to record 60Hz FPV:
bit.ly/power-play-dvr
If you convert a Nanohawk just like I show in this video, and you mount your props in the reverse direction (sometimes called "props out"), and you flash Emuflight 0.3.3, then you can use my full CLI dump: bit.ly/3ARdHHO
Here are the CLI to rotate board and remap motor (may require fixing the motor direction in ESC firmware). Works with any FC running Emuflight or Betaflight:
resource MOTOR 1 B07
resource MOTOR 2 B08
resource MOTOR 3 B10
resource MOTOR 4 B06
set align_board_yaw = 90
set yaw_motors_reversed = ON
