Discover research-grade imaging with Holmarc's BLRM3-TS Trinocular Microscope cost-effective upright brightfield system with 5MP CMOS camera and live measurement software for biomedical, pathology, and general lab applications.
This video showcases:
✅ Trinocular configuration (50/50 split) with 30° inclined head and 55-75mm IP adjustment
✅ Infinity corrected optical system with Plan Achromatic objectives (4X, 10X, 40X, 100X oil)
✅ WF10X eyepieces (FN20) with dioptric adjustment on both eyepieces
✅ Quadruple revolving nosepiece with precision click stops
✅ Double layer mechanical stage (75 x 50 mm travel)
✅ Coaxial coarse/fine focusing with Abbe NA 1.25 condenser
✅ Powerful 3W Koehler LED illumination with adjustable intensity
✅ 5MP CMOS camera (7 fps full resolution) + Micro Analyser software
⚙️ Technical Specifications
Model: BLRM3-TS
Configuration:
Type: Upright Brightfield
Observation Head: Trinocular (50/50), 30° inclined, 55-75mm IP adjustment
Eyepieces: WF10X, FN20, Dioptric adjustable (both)
Objectives (Infinity Corrected Plan Achromatic):
4X / 0.10 (WD 21 mm)
10X / 0.25 (WD 5 mm)
40X / 0.65 (WD 0.66 mm)
100X Oil / 1.25 (WD 0.36 mm)
Stage & Focusing:
Mechanical Stage: Double layer, 75 x 50 mm travel
Focusing: Coaxial coarse + fine mechanism
Condenser: Abbe NA 1.25 with IRIS diaphragm
Illumination:
3W white LED (Koehler), adjustable intensity
Power: 230V, 50Hz
Digital Camera:
Sensor: 5MP CMOS Color (1/2.5")
Active Pixels: 2592 x 1944
Frame Rate: 7 fps @ full resolution
Interface: USB 2.0 (C-mount)
Software: Micro Analyser (live measurements, image grabbing, PDF export)
Applications:
✅ Biomedical research and pathology
✅ General laboratory microscopy
✅ Live specimen observation
✅ Digital image analysis and measurement
✅ Educational and industrial quality control
📞 Get Quote: holmarc.com/trinocular_microscope_BLRM3_TS.php
🌐 Website: holmarc.com
📩 Mail us at sales@holmarc.com for more details
Why Choose Holmarc?
Made in India | ISO 9001:2015 Certified
Lab-proven reliability for research & industry
Global standards compliance
