SciTubeHD | High Voltage AC vs Flame @BrianDhvTinkerer | Uploaded July 2024 | Updated October 2024, 6 hours ago.
In this video, we explore the effect of high frequency, high voltage, alternating current from a Tesla coil on a burning Brazil nut. This makes a very clean yellow flame easy to see the effects.
PLEASE READ:
For more details on this set up including Gerber files please check here:
Please also check out ArcAngel Tesla coils channel for a great coil tuning video. If you decide on making this coil, here are the links:
LATEST FILES FOR DOWNLOAD
Schematic:
drive.google.com/file/d/1U3CpDZA1atoWu5OCEdDJ45-rcvkhTCXY/view?usp=sharing
Latest Gerber:
drive.google.com/file/d/1vwFNH3fk053L7H5P-xUdhL3pSneVlDkD/view?usp=sharing
BOM:
docs.google.com/spreadsheets/d/1rrraj2zCouSLZpCdsBU1_RHvjUGfeErY/edit?usp=sharing&ouid=100629004242817296916&rtpof=true&sd=true
pics:
drive.google.com/file/d/1tA92C3gCkSk3vCwhurm4nyQFcjrpOB2F/view?usp=sharing
we are working on a kit. Will keep you posted. We can presently offer the board and all components except the primary coil and secondary. This set up doesn’t need a top load. Our plan is to creat a 3D printed former to use with quarter inch soft copper tubing. Any secondary will work. I’m using a 3.5 inch diameter PVC pipe wound to 6 inches with 34 awg magnet wire. This resonates at 275 kHz with a 100 nF capacitor. The primary is 5 turns 1/4 inch copper tube 5.5 inch OD tapped at turn 3.25. This seems to work well
