E696. SO going down a rabbit hole to find a alternate solution for Amiga displays. I came across a 17" 4x3 looking LCD in 5*4 flat panel for 70$ range on amazon, figured looks good. lets give it a try, what sold me was BNC, component/composite, rca, built in loud speakers, and hdmi and vga. but would it work? is it worth it, i think it has use. check it out.
VGA input: supports 31KHZ input signal only
BNC input: supports 15KHZ input signal only
HDMI input: can support both 15KHZ and 31KHZ input signals, but this requires the use of a suitable signal converter / adapter. (pistorm framethrower or GBS style converter box?
im sure these will sell out fast. but here is the link
amzn.to/4bxzsAE
