My first setup was a bit heavy so I decided to do a little test. I printed the frame with only 80 percent of the original height. This saved me about 5g of weight. Full setup comes out at 62g without battery and 89g with battery. Flight times are at 3:30 minimum now and it has a bit more punch. Good setup for indoors and backyard but I think the real fun begins with a 3s setup.
I don't like the camera, image is not sharp and can't adjust. Ordered an other cam (Eachine TX03 with 1/3 CMOS), hope that will do better.
Setup:
Doinker Frame V2 ABS: thingiverse.com/thing:1676674
Racerstar BR1103 8000kv motors and RS6A 1-2s ESC: banggood.com/Racerstar-Racing-Edition-1103-BR1103-8000KV-1S-Brushless-Motor-RS6A-V2-BB2-Blheli_S-6A-1-2S-ESC-p-1096932.html?p=MI02017998062014105Q
Eachine Tiny Frsky 8CH PPM SBUS Receiver: banggood.com/Eachine-Tiny-QX90-Quadcopter-Parts-Frsky-8CH-PPM-SBUS-Receiver-Compatible-Frsky-X9D-PLUS-X9E-DJT-DFT-p-1079410.html?p=MI02017998062014105Q
FuriousFPV Piko BLX F3 FC: furiousfpv.com/product_info.php?products_id=41
Eachine TX02 NTSC Super Mini AIO 5.8G 40CH 200mW VTX 600TVL 1/4 Cmos FPV Camera: http://banggood.com/Eachine-TX02-Super-Mini-AIO-5_8G-40CH-200mW-VTX-600TVL-14-Cmos-FPV-Camera-p-1088368.html?p=MI02017998062014105Q
Turnigy Nano-Tech 450mAh 2s 65c battery
