Uploaded December 2024 | Updated September 2026, 1 week ago

---

What will happen if you don't have enough GND pins on your connector? Explained by Eric Bogatin

Links:
- About Eric: https://www.colorado.edu/faculty/bogatin/
- FEDEVEL courses: fedevel.com/courses

Questions?
- Ask on our Discord here: discord.gg/8a8dUcHmrx

Chapters:
00:00 The problem
06:40 The test explained
10:42 Ground disconnected
11:43 One Ground pin
17:33 Noise with 1 GND for ALL pins
25:11 Every other wire GND
33:11 Noise with 1 GND per EACH PIN
39:27 Disconnecting GND (from the first end)
42:30 Disconnecting GND (from the second end)

------------------------------------------------------
