I couldn't find a Quick Charger 2.0 ( QC ) car charger that has few QC on the same device. They either have 1 output, or if it has few, then there is 1 QC and the other are regular 5V. I decided to build one of my own that can be stacked and fit my needs and this video will show you the complete process from Design to building it.

Here are some links of what I have used in this video:
QC presentation:
dianyuan.com/upload/community/2014/08/14/1407998146-27019.pdf

CHY100:
ac-dc.power.com/products/chiphy-family/chy100
ac-dc.power.com/sites/default/files/product-docs/chy100_family_datasheet.pdf

ST eDesign studio:
my.st.com/analogsimulator

EasyEDA project:
easyeda.com/Weblearning/QC_Charger-85cbccd80ead4b9da4e14ce27ff4d8e3

USB load tester:
banggood.com/RD-DC3_7-13V-15W-Cilvil-And-Industrial-Grade-Electronic-Load-Resistor-USB-Interface-p-1187653.html?p=9R09143243493201512Z

USB power tester that can fit QC:
banggood.com/MantisTek-White-Tail-USB-Doctor-Voltage-Current-Detector-Power-Tester-p-1017785.html?p=9R09143243493201512Z
