In this video, I'll show you how I built a miniature trebuchet that packs a punch!

Affiliate links:
ORX Deburring Chamfer Tool: amzn.to/3wjkegX
xTool P2 55w Laser Machine: bit.ly/3Sp3wEz

Download the cut files:
DXF part files: drive.google.com/file/d/1AUTtDlUqQbAjQo2FecQjpPBtDBKEDbAL/view?usp=sharing
xTool Creative Space files: drive.google.com/file/d/1Tgjl_TQxSLt3PMnTnIw0sxNnblVVaslK/view?usp=sharing

Trebuchet frame cut from:
1x 300x450mm 6mm (1/4") plywood
1x 300x600mm 6mm (1/4") plywood

Hardware:
2x bearings 688-2rs
M8 threaded rod 195mm
M8 threaded rod 125mm
M8x50mm bolt
9x M8 nyloc nuts
12x M8 washers

2x M6 threaded rod 200mm
4x M6 nyloc nuts
16x M6 washer

6x M4x20mm screws

Misc:
Nylon string line (for sling)
2.5mm wire (for hook)
20x45mm webbing (for sling)
0.8~1kg of weights
