Uploaded July 2020 | Updated September 2026, 3 weeks ago

---

This is an Adjustable 76-108MHz FM Radio Receiver!
► Buy This KIT: bit.ly/2B7SIqI

This KIT is very simple to assemble, and it is also composed of a few components. The radio is drived by an SMD integrated circuit RDA5807PF, for some it may seem difficult to
solder SMD components, but it is not so.. below I leave you a link to my video tutorial in which I show you how to solder SMD components.
► My SMD Tutorial: youtu.be/IDnYecRidMU

● Visit ICStation: icstation.com


Chapters:
0:00 - Intro
0:30 - Unboxing
1:20 - Start Assembly
4:18 - End Assembly
5:00 - First Test
5:18 - Amplifier Test
6:20 - Circuit Diagram
6:28 - END
