Uploaded May 2025 | Updated September 2026, 1 week ago
This is the only Tramsquare Crossing in Japan, referred to as a Diamond Crossing since the tram and train lines cross each other in a somewhat diamond-like shape. There used to be other tram square crossings in Japan, but they have since been grade-separated. This is an interesting example of a Tramsquare with the tram and train operator (Iyotetsu) being the same company, so they operate all services over this crossing.
これは日本で唯一のトラムスクエア踏切で、路面電車と電車の線路がダイヤモンドのような形で交差することからダイヤモンド踏切と呼ばれています。かつては日本にもトラムスクエア踏切はいくつかありましたが、現在は立体交差化されています。これは、路面電車と電車の運行会社（伊予鉄道）が同じ会社であるため、この踏切を通るすべての列車を運行しているという、トラムスクエアの興味深い例です。
Trains usually cross over this crossing, seeing the crossing being down for a long amount of time
列車は通常この踏切を渡るため、踏切は長時間閉鎖される
This video provides a good amount of detail on this line and the voltage differences it has because it operates at the same voltage as the trams at 600V, whilst other lines operate at 750V
このビデオでは、この路線とその電圧の違いについて詳しく説明されています。他の路線は750Vで運行されているのに対し、この路線は路面電車と同じ600Vで運行されているためです。
youtu.be/hTOUaRSovn8?si=rYeiUUPc9H5BK5bZ
Comparing this to a tram square in Melbourne (Australia), where I am from, they work quite differently. Melbourne tram squares have a signal box by them to monitor the crossing, and the signaler changes the overhead over the crossing between our 600V trams and 1500V trains.
これを私の出身地であるオーストラリア、メルボルンのトラムスクエアと比べると、仕組みは全く異なります。メルボルンのトラムスクエアには、踏切を監視するための信号ボックスが設置されており、信号係が踏切上の架空線を600Vのトラムと1500Vの電車の間で切り替えます。
This crossing can also be referred to as the Takahama Line Crossing Number 40, or Otemachi Station Level Crossing
この踏切は、高浜線踏切40号線、または大手町駅踏切とも呼ばれます。
This Crossing Has:
- Sankosha SXDB031 All Directions LED Lights X4
- TOA Speaker (Japanese E-Bell) X2
- Japanese Crossbuck X2
- Daido Signal Incandescents X2
- Sankosha CA57-5 LED's X2
- Sankosha LH13? LED's X2
- Daido Signal Incandescent Train Direction Light X2
- Level Crossing Beware Sign X2
- Crossing Info/Emergency Contact Sign X1
- Daido Signal CG65-2030 Gate Mechanism X4
- Diado Signal CG66-0103A Gate Mechanism X1
- Diado Signal CG98-0201A Gate Mechanism X1
- Yellow & Black Bamboo Gate X6
- Japanese Signal Mast X2
- Daido Signal Base X2
Line/s (鉄道路線): Takahama Line (高浜線)
Operator (鉄道事業者): Iyotetsu (伊予鉄道株式会社)
Coordinates (座標): 33.840104, 132.755267
Timestamps (タイムスタンプ)
0:00 Intro (導入)
0:05 Tour Part 1 (シグナルツアー一)
2:57 Tram (路面電車)
3:22 Activation 1 (交差アクティベーション一)
6:19 Trams (路面電車)
9:03 Activation 2 (交差アクティベーション二)
11:24 Activation 3 (交差アクティベーション三)
13:57 Tour Part 2 (シグナルツアー二)
14:53 Activation 4 (交差アクティベーション四)
17:23 Tour Part 3 (シグナルツアー三)
20:16 Trams (路面電車)
20:42 Activation 5 (交差アクティベーション五)
23:22 Tram (路面電車)
23:36 Activation 6 (交差アクティベーション六)
26:45 Tour Part 4 (シグナルツアー四)
27:37 Activation 7 (交差アクティベーション七)
30:10 Crossing Pics (写真)
30:40 Various other Trains & Trams at the level crossing (路面電車と電車)
43:30 Outro (アウトロ)
翻訳が悪かったらごめんなさい、Google翻訳を使用しています
I visited this city just to film this level crossing, over the last couple years I had slowly started doing research on this crossing after I first found out about it a few years ago, I managed to pinpoint it on a map and promised to myself If I were to ever visit Japan, I must go and film it. When the time came around that I had the opportunity in November last year, I took that to my advantage and went on a Solo Adventure around Southern Japan. I checked out Teardrop crossings around Kumamoto, then travelled to Hiroshima to see ground 0, then I caught a ferry across to Matsuyama here where we see the Tramsquare Level Crossing. Following the visit here, I also went to Yokkaichi and filmed some cylinder bells. It was an amazing adventure around a foreign country to me, where I got to explore various environments.
My Socials
Main Channel: youtube.com/c/TazzieTransport
Second Channel: youtube.com/c/TazzieT
Instagram: instagram.com/tazzie.transport
Music by TELL YOUR STORY music by ikson™: ikson.com/tell-your-story
And/Or youtube.com/@MaxwellDexter
Filmed: Nov 2024
