ctrlX CORE as Smart HMI Part-1
In this video, you will see how to create a basic layout for Smart HMI which is reading simulated values from an OPC UA server.
🔥Access all the ctrlX CORE related videos in our exclusive course on ctrlX CORE available at 👉: codeandcompile.com/course/ctrlx-core-bosch-rexroth

Reference links:
👉About ctrlX AUTOMATION: apps.boschrexroth.com/microsites/ctrlx-automation/en/?utm_medium=social&utm_source=youtube.com&utm_campaign=en_ae_ctrlx_wk1123&utm_content=developer-engineer-director&utm_term=1503-ytrs
👉More about Smart HMI: apps.boschrexroth.com/microsites/ctrlx-automation/en/ctrlx-world/partner/smart-hmi-en/?utm_medium=social&utm_source=youtube.com&utm_campaign=en_ae_ctrlx_wk1123&utm_content=developer-engineer-director&utm_term=1503-ytrs
👉More about Smart HMI WebIQ Server: developer.community.boschrexroth.com/t5/store-and-how-to/smart-hmi-webiq-server/ba-p/18412?utm_medium=social&utm_source=youtube.com&utm_campaign=en_ae_ctrlx_wk1123&utm_content=developer-engineer-director&utm_term=1503-ytrs
👉Get WebIQ Designer: developer.community.boschrexroth.com/t5/store-and-how-to/smart-hmi-webiq-server/ba-p/18412?utm_medium=social&utm_source=youtube.com&utm_campaign=en_ae_ctrlx_wk1123&utm_content=developer-engineer-director&utm_term=1503-ytrs

Timeline:
0:00 - Introduction
0:30 - What is WebIQ
2:33 - Example 1- Create your first HMI Project
4:45 - Adding Header, Footer and Content
11:40 - Adding multi screen panel
20:30 - Adding WebIQ internal OPC UA Server
21:30 - Adding OPC UA tags
25:03 - Adding Widgets on the screen
26:25 - Connecting the widgets with the OPC UA Tags
30:35 - Running the HMI project on the ctrlX CORE
34:20: Outroduction
