I've read about large coil crystal radios and always wondered if they were any good and worth the trouble. I bought a couple embroidery hoops and wrapped one with single strand copper, and the other with Litz wire. I tested them against a regular coil crystal radio of the same circuit layout. There were assumptions, leading to mistakes; in the end it worked out!
MATERIALS
- 500uH variable capacitor (normally 365uH)
- Capacitor mount
- Litz wire (10/46)
- 309mm embroidery hoop
- Crystal earphone
- 1n34a diode
- 10k to 30k ohm resistor
- Fahnestock clips (optional)
- Screws, washers
- Base 15cm x 10cm x 3cm
- Mast 40cm tall x 9cm wide (paneling)
- Zip ties
- Thread
- White glue
- Wire ends (optional)
- Shrink wrap (optional)
