Part 2 - My Creality CR6SE Kickstarter burned up due to a manufacture defect that caused a couple parts, and connected devices through USB to burn up! The frame is shorting to the +24V DC due to a short from the heated bed, the USB shield is now at 24V relative to the USB ground. This manufacture defect killed my board, Raspberry Pi, and Webcam. During the last stream we found it it also killed my display! That explains where the smoke came from. I hope to have this machine operating safely, or as safe as I can make it by the end of this stream. The display and other parts have been ordered!
