Claas Axion 870 CMATIC | 300 Horsepower Tractors with CVT Transmissions | TractorLab
12 videos about:
Claas Axion 870 CMATIC
Deutz-Fahr 9310 TTV Agrotron
Fendt 930 Vario
Case IH Optum CVX 300
Challenger MT665E
John Deere 7290R AutoPowr
New Holland T7.315 AutoCommand
McCormick X8.680 VT-Drive
JCB Fastrac 8310
Massey Ferguson 8730 Dyna-VT
Steyr 6300Terrus CVT
Valtra S294
New Video: goo.gl/7jfYxX
Most Popular Video: goo.gl/cmMCYt
Subscribe: goo.gl/jYJgLu
facebook: https://www.facebook.com/Agricultural...
Google+: https://plus.google.com/communities/1...
Twitter: twitter.com/TractorLab
TractorLab
Strong at heart.
A 6-cylinder, 6.7 litre FPT (Fiat Powertrain Technologies) NEF 6 engine gets to work under a one-piece bonnet. The engine meets the requirements of the Stage IV (Tier 4) emissions standard by incorporating exhaust gas aftertreatment with urea. It uses the latest common rail 4-valve technology, charge-air cooling and a variable geometry turbo (VGT).
Constant output.
The CLAAS-specific engine performance curve provides full torque in a wide engine speed range, guaranteeing constant output and power delivery when they are needed. This makes it easy to save fuel while working at a low engine speed and maximum torque with the ECO PTO, or to work at rated speed with a full reserve.
SCR – the urea-based solution.
SCR stands for selective catalytic reduction, a process in which nitrogen oxides are converted into water and pure nitrogen. This is achieved by using a synthetic aqueous solution of urea (AdBlue®), which is carried in an additional tank. Exhaust gas aftertreatment enables the combustion process in the engine to function at the optimum level.
Fully integrated SCR system.
When designing the AXION 800 series, all the components required for exhaust gas aftertreatment were considered from the outset. Full visibility and accessibility are therefore guaranteed. The diesel oxidation catalytic converter (DOC) is positioned under the bonnet immediately behind the turbocharger because it needs high exhaust temperatures to produce an optimum reaction. The SCR catalytic converter is an integral part of the exhaust system and is located on the right-hand side of the tractor.
The AXION 870 CMATIC delivers up to 295 hp thanks to the intelligent CLAAS POWER MANAGEMENT (CPM) electronic control system. Additional boost power is available for PTO work from 7 km/h, for transport operations and also for the fan drive, significantly increasing the performance and versatility of the AXION 870 CMATIC.
Efficient and user-friendly.
CMATIC is the name of the continuously variable transmission technology used in CLAAS tractors. In the AXION 800 series a ZF Terramatic transmission provides efficient conversion of engine power. In this split-power, continuously variable transmission, the four mechanical ranges are automatically selected by multidisc clutches. There is no need to shift between ranges manually.
The high mechanical component in the power transmission provides outstanding efficiency and low fuel consumption in every speed range.
Simple, straightforward operation.
The CMATIC transmission has three operating modes: accelerator pedal, drive lever and manual mode. In the first two modes, forward speed can be controlled by the accelerator pedal or drive lever. The engine speed and transmission ratio are adjusted automatically – for optimum efficiency and optimised fuel consumption. In manual mode, the driver chooses the engine speed and transmission ratio. Automatic engine and transmission control is not active.
Tailor-made speed ranges.
With the CMATIC transmission, three speed ranges can be pre-selected in both directions of travel. The active range is displayed in the CEBIS or CIS and can be changed while the tractor is in motion using two buttons. The lower the maximum preset value for the range, the more accurately the forward speed can be controlled.
A cruise control speed can be saved for all the ranges while the tractor is moving by pressing the button on the drive lever. The cruise control speeds can also be pre-set on the CEBIS or CIS terminal.
CMATIC allows drivers to create their own profiles according to the job in hand. Intelligent CMATIC transmission technology enables you to use the full power of your AXION economically and productively – with maximum operator comfort.
claas axion 800
claas axion 870 cmatic
claas axion 870 c matic
300hp tractor
300 hp tractor
cvt transmission
ivt transmission
cvt tractor
cvt tractor transmission
fendt cvt transmission
massey ferguson cvt transmission
Case IH cvt transmission
john deere cvt transmission
john deere ivt transmission
CMATIC transmission
Claas CMATIC transmission
Claas Axion 800
Claas Axion 800 Series
CMATIC
