Just a nice long video to show to the real time process of assembling Vectrex LED Boards. I completed 20 start to finish in two hours. Half the time is cleaning them.
Another video showing the operation of this board:
youtube.com/watch?v=gs0RqsXG9QE
Another video showing other parts of the process of building this board:
youtube.com/watch?v=gfcdljKq0YI
Tools:
1. The trinocular microscope is the same one Scotty from Strange Parts uses. Check out his video and description for a link to buy. If you happen to be in Shenzhen, I can hook you up with Sue May like Scotty did for me, and you can pick one up directly in the SEG Electronics Building. It will fit most likely in your overhead carry on! youtube.com/watch?v=MBFyGzrClsI
2. Kimtech kimwipes
3. 91% isopropyl alcohol and go crazy with the 99% tech grade stuff for the final wipe.
4. Solder - Kester SN63PB37 0.015" - My exact part# is 24-6337-2611 but you can't get it anymore, it's $$$$ neobits.com/kester_solder_24_6337_2611_bx_kester_lead_solder_p12396973.html but you can use this part # instead which is the same thing: 24-6337-0007
5. Flux is Chipquik SMD291 digikey.com/product-detail/en/chip-quik-inc/SMD291/SMD291-ND/355201
6. Soldering Iron Hakko FX951 and Tips:
- T15-JL02 bent hook conical tip has 0.2mm radius tip
- T15-D16 narrow chisel tip is 1.6m wide
- T12-BCM2 hoof/drag soldering tip is 2mm wide
