Uploaded November 2022 | Updated September 2026, 2 hours ago
This is Part 2 of my SSQA Remote Control project videos. Be sure to watch Part 1 first, then watch all of Part 2 before buying any hardware and starting your build.
Materials:
* ECO LLC 8 Inch 8" 225lbs 0.55in/sec 12VDC Linear Actuator: amzn.to/3thXuco
* 15 Ft 6AN ID Braided Stainless Steel Fuel Line Hose: amzn.to/3Up0aAW
* Waterproof Latching Polarity Reversing Rocker Switch: amzn.to/3thdknS
* GS Power 16 Gauge Wire 100 Ft Two Conductor Copper Wire: amzn.to/3FZCCOM
* 2-Pin Waterproof Electrical Connectors, 10 Pack: amzn.to/3gnE2EE
* Alex Tech 25ft – 1/4 inch Split Wire Loom: amzn.to/3F2qo7e
* Alex Tech 25ft – 1/2 inch Split Wire Loom: amzn.to/3AP7Apk
Recommended Special Tools:
* Crimping Tool for Waterproof Connectors: amzn.to/34fS5K7
* Starrett 18A Automatic Center Punch: amzn.to/3rr6Z9m
Chapters:
00:00 Introduction
00:28 Design Dimensions
01:58 Making the Actuator Extensions
03:09 Assembly & Installation
05:01 Testing the Mechanism
05:56 Wiring the Electrical Controls
06:20 Choosing and Installing the Switch
11:44 Connecting to the Fuse Box
13:05 Wiring to the Linear Actuator
19:21 Testing the Electrical Controls
20:01 Real-world Test
21:12 Final Thoughts & Recommendations
Note: Links to Amazon products are Amazon Affiliate links that won’t cost you any extra, but will help support my efforts with a small commission on qualified products. Thanks for your support!
Visit DIYMyWay.net: diymyway.net
Follow Me on Twitter: twitter.com/diymyway
Visit my Amazon Affiliate Store: amazon.com/shop/diymyway
#diy #outdoors #tractors #kubota #ssqa
